The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity

جزئیات محصول:

محل منبع: چین
نام تجاری: Charming
گواهی: CE,ROHS,LVD,EMC,CB,BIS,UL
شماره مدل: P2.22

پرداخت:

مقدار حداقل تعداد سفارش: 10 عدد
قیمت: قابل مذاکره
جزئیات بسته بندی: پرونده کارتن ، کیس چوبی ، پرونده پرواز
زمان تحویل: 7 روز کاری پس از پرداخت
شرایط پرداخت: Western Union ، L/C ، T/T ، PayPal ، Cash
قابلیت ارائه: 10000 قطعه در هفته
بهترین قیمت مخاطب

اطلاعات تکمیلی

بعد (میلی متر): 320*160 میلی متر روشنایی (CD/): 700 سی دی در متر مربع
تراکم پیکسل (نقطه/㎡): 202500نقطه/㎡ سطح حفاظت: IP42
سطح خاکستری: 14-16 بیتی استاندارد LED: SMD2020
حالت اسکن: 1/36 اسکن حداکثر قدرت ماژول (W: DC 5V
طول عمر: 100000 ساعت
برجسته کردن:

P2.22 LED video wall display,202.5K pixel density LED display,700 nits brightness video wall

,

202.5K pixel density LED display

,

700 nits brightness video wall

توضیحات محصول

The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity

Production Detail


The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 0



Specification


Type Number P2.22
Dim ension(MM) 320*160MM
Module Maximum power(w) 20W
Best Viewing Distance(M) ≥2.2M
LED Standard SMD2020
Scan Mode 1/36Scan
Pixel Density(Dot/m²) 202500Dot/m²
Refresh Rate(Hz)
7680Hz
Brightness(CD/ m²)
>700
Pixel Pitch(MM) 2.22
Protection Level
IP42
Grey Level
14-16bit
Working Temperature
-20~50°C
Working Humidity
10%~90%RH
Life Span
≥50000 Hours
Working Voltage
DC 5V



The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 1The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 2The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 3The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 4

Company profile

The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 5

The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 6

Certificate

The First P2.22 to Combine 202.5K Pixel Density with 700 Nits Brightness for Premium Clarity 7

Question



1: Do you accept sample orders?
We support sample orders for both LED modules and complete screens for quality inspection.

2: What's the production lead time?
Modules ship in 1-5 days; screens under 100㎡ deliver within 15 working days.

3: Quality guarantee?
All products come with 12-month warranty.

4: How to place an order?
Just tell us your screen size and application!

5: Most economical shipping method?
Air is faster but expensive; sea freight saves money!

6: Payment options?

Bank transfer accepted; payment recommended for security.Let me know if you'd like any adjustments to these versions!
