High Refresh Rate GOB Technology Foldable LED Poster Display with Intelligent Mobile Control
جزئیات محصول:
| محل منبع: | چین |
| نام تجاری: | Charming |
| گواهی: | CE, ROHS, LVD, EMC, CB, BIS, UL |
| شماره مدل: | P1.86، P2، P2.5 |
پرداخت:
| مقدار حداقل تعداد سفارش: | 2 عدد |
|---|---|
| قیمت: | قابل مذاکره |
| جزئیات بسته بندی: | جعبه کارتن، جعبه چوبی، کیف پرواز |
| زمان تحویل: | 30 روز کاری پس از پرداخت |
| شرایط پرداخت: | L/C ، T/T ، Western Union ، PayPal ، Cash |
| قابلیت ارائه: | 500 قطعه در هفته |
|
اطلاعات تکمیلی |
|||
| زاویه دید: | 140 درجه | سطح حفاظت: | IP43 |
|---|---|---|---|
| مواد کابل شبکه: | آلیاژ آلومینیوم | روش نگهداری: | تعمیر و نگهداری جلو |
| سطح خاکستری: | 14-16 بیتی | دمای کاری: | -20 تا 40 درجه |
توضیحات محصول
High Refresh Rate Foldable LED Poster Screen with GOB Technology and Intelligent Mobile Control
Advanced foldable LED poster screen featuring high refresh rate technology, GOB protection, and intelligent mobile control for superior display performance.
- High Refresh Rate
- GOB Technology
- Intelligent Mobile Control
| Parameter | P1.86 | P2 | P2.5 |
|---|---|---|---|
| Pixel Pitch (mm) | 1.86mm | 2mm | 2.5mm |
| LED Standard | SMD1515 | SMD1515 | SMD2020 |
| Scan Mode | 1/43Scan | 1/40Scan | 1/32Scan |
| Pixel Density (dot/m) | 288906 | 202500 | 160000 |
| Brightness (CD/m²) | 600 | 600 | 800 |
| Dimension | 640*1920*490mm |
| Max. Power | 600W |
| Cabinet Weight | 48.8kg |
| Refresh Rate | 7680Hz |
- Splice the boxes into the required size and shape, aligning holes with quick locks to secure the boxes
- Identify power and signal cables, then insert them into the corresponding box connections
- Connect the main signal and power cables to the computer and controller, then debug the screen for successful operation
We offer multiple packaging options including carton cases, wooden cases, and flight cases. Different products are configured with appropriate packaging to ensure optimal screen protection during transport.
